Key Features
- Supports AMD Ryzen™ 7000 Series Desktop Processors
- Supports DDR5 Memory, up to 6400+(OC) MHz
- Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
- 2.5G LAN and Intel Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
- Lightning M.2: Running at PCIe Gen 4 maximizes performance for NVMe based SSDs
- Lightning USB 20G: Built-in USB 3.2 Gen 2x2 port, offers 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1
- AUDIO BOOST 5: Reward your ears with studio grade sound quality for the most immersive gaming experience
General
- Processorsocket
- AMD AM5
- Chipset
- B650
- Formfaktor
- ATX
Memory
- Memory Type
- DDR5
- Kanaler støttet
- Dual Channel
- Memory frequency (base)
- 4 800 MHz
- Memory frequency (OC)
- 6 600 MHz
- Memory slots
- 4 pcs.
- Max Memory Supported
- 128 GB
Expansion Slots
- PCIe x16
- 2 pcs.
- PCIe x1
- 1 pcs.
Storage Devices
- M.2 slots
- 3 pcs.
- SATA ports
- 6 pcs.
Communications
- Wi-Fi
- Ja
- WiFi Standard
- AMD Wi-Fi 6E
- Bluetooth
- Ja
- Bluetooth standard
- 5.2
Internal I/O Connectors
- TPM
- Ja
Rear Panel Ports
- USB type-A
- Ja
- USB type-C
- Ja
- HDMI
- Ja
- DisplayPort
- Ja
- AUX out
- Ja
Størrelse & Vekt
- Width
- 243,84 mm
- Lengde
- 304,8 mm
Pakkeinformasjon
- Pakkestørrelse
- 350 x 271 x 76 mm
- Pakkevekt
- 1,78 kg
Pakkeinformasjon (5 stk)
- Pakkestørrelse
- 285 x 380 x 370 mm
- Pakkevekt
- 9,60 kg
