POWERFUL AV SWITCHES MADE SIMPLE
Pre-configured to get you up and running faster.
Switching engineered for 1G AV over IP with versatile mounting options for under a table or behind a display. Pre-configured for out of the box functionality!

Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.

Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.

Sleek, Quiet Design
Less fan noise, and mounting ears included for under-table or wall mounting.

Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4250 (and M4300) switches.

FAST, EASY CONFIGURATION FOR AV PROS
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.

FOCUS ON THE EVENT NOT FAN NOISE
Most models have quiet mode which greatly reduces fan noise, and some models are even fanless.

DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOX
With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.

MAXIMIZE PERFORMANCE WITH NETGEAR ACCESS POINTS
Enable powerful, reliable WiFi at your location with WAX600 Series PoE access points.



Managed
Ja AV Web user interface with AV templates. Third party support : Domotz
Formfaktor
Desktop

General

Formfaktor
Desktop
Switching capacity
1 Gbit/s
Primary Port Speed
1 Gbit/s
Primary Ports
8 x
SFP Ports
2 x SFP+

Features

PoE
Ja PoE+
PoE Portar
8 x
PoE Effect/Port
30 W
PoE Budget
220 W
Switch stacking
Nei
IGMP Support
Ja Enhanced (NETGEAR IGMP Plus™)

Størrelse & Vekt

Width
210 mm
Dypde
140 mm
Høyde
40 mm
Weight
0,967 kg

Additional Information

Power consumption
257,9 W With PoE
Included Accessories
M4250-8G2XF-PoE+ (GSM4210PX), Power Adapter, Power cord(s), Console USB Type-C cable, Flat brackets for desktop or wall mounting, Rubber footpads for tabletop installation, Installation guide

Pakkeinformasjon

Pakkestørrelse
286 x 220 x 104 mm
Pakkevekt
2,98 kg

Pakkeinformasjon (6 stk)

Pakkestørrelse
300 x 570 x 250 mm
Pakkevekt
17,00 kg
