High-Performance with webOS 6.0
webOS 6.0, upgraded in SoC and web engine, is available on SM5J for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI and provides to SI or/and developers simple app development tools such as SDK (Software Development Kit), SCAP, sample applications.s
Key Features:
• Brightness(Typ.) : 400 cd/m²
• Bezel : 13 mm (T/R/L), 18 mm (B)
• Depth : 55.5 mm
• Interface : HDMI(3) /USB 2.0/ RS232C/ RJ45/ IR / Audio Out
• Built-in Speaker : 10W + 10W
Various Sensor Connection
LG webOS smart signage platform helps to easily provide additional solutions by supporting simple connections with external sensors* such as GPIO, NFC/RFID, temperature sensors, etc., via USB plug-in.
* External sensors need to be purchased separately and tested for compatibility with webOS platform.
Mobile & Web Monitoring
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of the SM5J series displays in different locations in real-time. It is available on internet connected devices, allowing you to flexibly and rapidly respond to emergency situations.
* The mobile devices need be connected with the Signage IP address and can control one Signage at a time.
** Control Manager is optimized for Google Chrome 56 version and above.
Compatible with AV Control System
The SM5J series supports Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.
* Network based control
Content Sharing
Content Mirroring among devices is available on a Wi-Fi network.
Wireless Access Point
The SM5J series operates as a virtual router which can be an wireless access point for mobile devices.
Display
- Operating Hours
- 24/7
- Image diagonal
- 32 "
- Resolution
- 1920x1080
- Lysstyrke
- 400 Nits
- Portrait
- Ja
Functions
- Protective Glass
- Nei
- Videowall
- Nei
- Outdoor use
- Nei
- TV Tuner
- Nei
- Innebygd høytaler
- Ja 2x10W
- Mediaplayer
- Integrated WebOS 6.0
Communication
- Ethernet
- Ja
- Wi-Fi
- Built-in
- Wireless image sharing
- Ja
Energy
- Power Supply
- AC 100-240 V~, 50/60 Hz Built-In Power Supply
- Consumption Typical
- 55 W
- Consumption Max
- 75 W
Dimensions and weight
- VESA mount interface (mm)
- 200x200
- Width
- 729,4 mm
- Høyde
- 428,9 mm
- Dypde
- 55,5 mm
- Net weight
- 5,7 kg
Additional information
- Included Accessories
- Remote Controller, Power Cord, QSG, HDMI Cable, Phone to RS-232C Gender
- Warranty
- 3 år swap
Pakkeinformasjon
- Pakkestørrelse
- 810 x 510 x 132 mm
- Pakkevekt
- 6,70 kg
- Strekkode
- 8806091356505
