W−3H2 is a 4K HDR HDMI dual insert extender that extends the HDMI cable distance between the HDMI player and the HDMI display by reclocking and equalizing the HDMI signal. Placing W−3H2 in the transmission path, removes dropout and digital noise (sparkles) in your picture that may result from using long HDMI cables.

  • Extends HDMI Transmission Distance — Extends 4K@60Hz (4:4:4) signals up to 20m from the source (10m from the source to the HDMI Extender, and 10m from the HDMI extender to the display).
  • Supports the DDWG standard for HDMI compliant displays.
  • HDMI Support — Supports HDR10, ARC, CEC, deep color, x.v.Color™, Lip Sync, 7.1 PCM, Dolby TrueHD, Dolby atmos DTS–HD, 2K, 4K, and 3D Dolby Vision as specified in HDMI 2.0.
  • Supports the DDWG standard for HDMI compliant displays.
  • Kramer reKlocking™ & Equalization Technology — Rebuilds the digital signal to travel longer distances.
  • Content Protection — HDCP 1.4 and HDCP 2.2 compliant.


General

Application
Connection module

Connections

HDMI
Ja Up to 4K 60Hz (4:4:4)
DisplayPort
Nei
USB type-C
Nei
USB type-A
Nei
VGA
Nei
DVI
Nei
Audio 3.5mm
Nei
Balansert lyd
Nei
Ethernet
Nei
Kabelgjennomføring
Nei
230V Strøm
0 pcs.

Størrelse & Vekt

Length
50,5 mm
Width
28 mm
Dypde
47 mm
Net weight
0,17 kg

Additional information

Farge
Svart
Included Accessories
Power adapter and cord
Warranty
7 år

Pakkeinformasjon

Pakkestørrelse
50 x 100 x 100 mm
Pakkevekt
76 g
