DSP-AEC-1410 | AUDIO DSP WITH AEC, 12-IN/8-OUT AND 2x2 USB
Advanced DSP with freely assigned processing blocks, GPIO and camera control
Sometimes you need to go big. The DSP-AEC-1410 offers 12 analog ins and 8 analog outs, as well as 8 GPIO ports plus RS232 and RS485 control. The front panel USB port can operate as a two-channel USB record/playback channel, giving the unit a total of 14 inputs and 10 outputs.
As the name suggests, the DSP-AEC-1410 is equipped with advanced acoustic echo cancellation, making it ideal as a centerpiece in web conference installations to eliminate unwanted feedback. Other DSP facilities include EQ, dynamics, mixer, and matrix, which can be freely configured via five processing blocks per channel. PTZ camera control is also supported, allowing you to choose which channel’s thresholds should trigger the camera’s presets.
For critical applications, two parallel-wired 1410s can be set up in Redundancy Mode, for automatic changeover in case of power or component failure.
As an option, programmable control panels (sold separately) offer the end user hands-on control to parameters set by the integrator.
- Styring
- Ethernet/IP (RJ-45)
- Styring
- GPI/O x8
- Styring
- RS-232, RS-485
General
- Produktserie
- TiGHT AV DSP
- Applikasjon
- Fixed I/O
Connections
- Ethernet
- Ja
- Lydinnganger
- Euroblock line x12
- Lydinnganger
- USB-B
- Lydutganger
- Euroblock line x8
- Lydutganger
- USB-B
- Dante
- Nei
- Wi-Fi
- Nei
Energy
- Power Supply
- AC110~240V 50Hz-60Hz internal power supply
Størrelse & Vekt
- Width
- 482 mm
- Dypde
- 264 mm
- Høyde
- 44 mm
- Net weight
- 3 kg
Additional information
- Applikasjon
- 19" Rack, 1U
- Included Accessories
- 7x 12-pin and 1x 6-pin Terminal Block connectors, 1x 1,5m USB 2.0 cable (A to B), 1x EU AC power cable, 1x UK AC power cable, 1x Screwdriver, 4x Rubber Feet
- Warranty
- 5 år
Pakkeinformasjon
- Pakkestørrelse
- 353 x 545 x 91 mm
- Pakkevekt
- 3,51 kg
