Ultra-small but powerful multimedia player, powered by 12th generation Intel® processor and UHD graphics
The DEN5128 is an ultra-small media player with Intel® 12th Gen ADL-U/H Core I Processor and Intel® UHD Graphics support 4K@60 on two HDMI2.0 display. Another two USB type C port can transfer to 2x DP output total support 4x display. Performance hybrid architecture, combining Performance-cores (P-cores) and Efficient-cores (E-Cores) to deliver balanced single-thread and multi-threaded real-world performance.
UHD (4K) content playback
DEN5128 is capable of driving 2x UHD (4k) content. With a resolution that goes up to 3840x2160 pixels your content will be close to perfect. This feature makes the players that are capable of delivering content that is fluent and stutter free in UHD (4k).
Small form factor
The size of DEN5128 is 117x35.8x111 mm, only 0.46L, this form factor ensures an easy integration into kiosks or behind screens with VESA mount bracket.
Dual HDMI2.0 output
DEN5128 support 2x HDMI2.0 output, it is good for easy digital signage application to connect to dual same display for menu board or advertisement playback.
Intel Core-i Platform
12th Gen Intel® Core mobile processors bring next generation performance across a full portfolio of options. With Intel’s revolutionary performance hybrid architecture, Intel® Thread Director6 intelligently moves workloads across performance cores—or “P-cores”—to optimize responsive, single-threaded performance, and efficient cores—or "E-cores"—to accelerate efficient, scalable, multi-threaded performance.
Prosessor
- CPU modell
- Intel i5-1240P, 12th Gen Alder Lake Socket: CPU on board
Memory
- Memory Type
- DDR4 SO-DIMM
- Max Memory Supported
- 64 GB
- Memory slots
- 2 pcs.
Graphics
- GPU Modell
- Intel® UHD Graphics for 12th Gen Intel® Processors
- Display Connections
- 2 pcs. UHD (4k) content
Storage
- Storage type
- M.2 SSD x 2
- Storage size
- 128 GB
Connections
- HDMI
- Ja x2 (HDMI 2.0)
- DisplayPort
- Nei
- USB type-A
- Ja x4
- USB type-C
- Ja 2x USB Type C w/DP
Communication
- Ethernet
- Ja 100/1000/2500Mbps
- WiFi
- Nei Optional module: M.2 slot x1, 2230(key E for wifi)
- Bluetooth
- Nei
Energy
- Power Supply
- AC 100 ~ 240V, 90W (19V, 4.74A) AC Adapter
Størrelse & Vekt
- Width
- 117 mm
- Dypde
- 111 mm
- Høyde
- 35,8 mm
- Net weight
- 1,1 kg
Additional Information
- Warranty
- 2 år
Pakkeinformasjon
- Pakkestørrelse
- 195 x 172 x 101 mm
- Pakkevekt
- 1,09 kg
