TECHNICAL SPECIFICATIONS & MANUAL
General Specifications
Dimensions: 140 (L) x 140 (W) x 27 (H) mm
Net Weight: 245g
Operating Ambient Temperature: 0–40 °C
Warranty: 6 Years
Fan Specifications
Fan Speed: 400—2800 rpm (PWM controlled), 0 rpm below 3 % PWM
Airflow: 95,00 cfm | 161,40 m³/h
Static Pressure: 4,18 mmH2O
Fan Bearing: Fluid Dynamic Bearing
Typical Voltage: 12 V DC
Start Up Voltage: 3.9 V DC
Current: 0.35 A
Cable Length: 400 mm
Connector: 4-Pin PWM Connector
General
- Power Connector
- 4-pin PWM
- Vifte størrelse
- 140 mm
- Luftstrøm
- 95 cfm
- Static pressure
- 4,18 mmH2O
- RPM
- 2 800 rpm
- Units per package
- 1 pcs.
Pakkeinformasjon
- Pakkestørrelse
- 176 x 172 x 40 mm
- Pakkevekt
- 321 g
Pakkeinformasjon (39 stk)
- Pakkestørrelse
- 519 x 188 x 479 mm
- Pakkevekt
- 930 g
